Product Features：
◆ Independent 24V hydraulic power unit for option.
◆ Integrates gravity-adaptive loading with automatic obstacle avoidance and reset, providing powerful cutting, high-speed operation, and extended snow-throwing range.
◆ Allows ±30° left-right angling for efficient removal of light snow from sidewalks and bicycle lanes.
◆ Built with reinforced steel frame and quick-change bolt on the cutting edge (thickness: 16 mm); optional rubber edge available for delicate surface protection.
|
VTBM Snow Plow Specifications |
|||||
|
Model |
Unit |
BM1896 |
BM18120 |
BM18140 |
BM18160 |
|
Overall Length |
mm |
1680 |
1680 |
1680 |
1680 |
|
Overall Width |
mm |
2440 |
3000 |
3600 |
4000 |
|
Overall Height |
mm |
1175 |
1230 |
1230 |
1230 |
|
Deflection Angle |
Degree ° |
±30 |
±30 |
±30 |
±30 |
|
Operating Speed |
km/h |
3-60 |
3-60 |
3-60 |
3-60 |
|
Overall Weight |
kg |
1050 |
1150 |
1215 |
1280 |
